Deep learning, AI, edge computing，Cloud storage, cloud computing, big data, security monitoring, LOT, etc.
| Components | Specification |
| Dimensions(WxDxH) | 438mm x 480mm x 177mm. |
| Materials | Quality fine 1.0mm SGCC steel. |
| Color | Black painting in front panel, steel color in the body of chassis. |
| Drivers bay | 4*U.2NVMe ssd bays. |
| Cooling Fan | 3 X 120mm, optional 2*8038mm fans on rear board. |
| PSU form factor | CRPS power supply module + GW-BKPH2CBO power supply backplane. |
| M/B form factor | Support max 12''*13'' motherboard+Micro X10DRG-Q. |
| Epansion space | 11 vertical PCI expansion slots. |
| Connector | Two front accessible USB2.0 ports. |
| System Control | Power LED*1, HDD LED*1, NIC LED*2, Power SW*1, Reset*1. |
| Applicarion | AI, edge computing, deep learning, rendering, GPU computing, etc. |
| Product Features: | |
1.Conformed with EMC design standard to prevent from electromagnetic interference. | |
| 2.Support motherboard size up to 12''*13'' +Micro X10DRG-Q, and 4*U.2NVMe ssd bays, CRPS power supply module + GW-BKPH2CBO power supply backplane. | |
| 3.The chassis has good ventilation system 3 X 120mm, optional 2*8038mm fans to make sure the system work steadily. | |
