Product model:E08-48

Cloud storage, cloud computing, big data, security monitoring, LOT, etc.

Components	Specification
Dimensions(mm)	382(L)437(W)H165(H).
Materials	1.2mm SGCC Zinc-Coated Steel.
Colour	Handle and lug are all sandblasted black (other steel plate's natural color).
System disk	60/64G Msata, optional 128G Msata.
Cooling Fan	Standard quotation with 3pcs 12038H ball bearing fans.
PSU form factor	1U 1600W power supply, optional 1U 1800/2200W
M/B form factor	8-card in-line motherboard.
I / O expansion	1Gigabit LAN, 1HDMI, 6DC 12V Input, 8DC 12V Output(GPU)
CPU	AMD A6-4455M.
RAM	DDR3 4G notebook memory, optional DDR3 8G notebook memory
Connector	Two front accessible USB2.0 ports.
System Control	1Power LED, 1HDD LED, 1*Power SW.
GPU card slot	Support GPU cards with thickness ≤ 48mm, length ≤ 310mm and height ≤ 117mm, and mainstream graphics cards such as 1660s / 570 / 580 / 2080ti.
Applicarion	Cloud storage, cloud computing, Render, etc.

Product Features:
1.Conformed with EMC design standard to prevent from electromagnetic interference.
2.Support motherboard 8-card in-line motherboard, HM65 chipset, 60/64G Msata, optional 128G Msata，DDR3 4G notebook memory.
3.The chassis has good ventilation system 3pcs 12038H ball bearing fans to make sure the system work steadily.
