Intelligence, Communication, Electric Power, Outdoor Maintenance and Industrial Construction
| Components | Specification |
| Dimension | 358(L) x 256(W) x 140(H) |
| Material | Aluminum magnesium alloy, Build a variety of testing and monitoring systems, suitable for various harsh environments |
| CPU | Intel D2550 +NM10 ( optional I3/I5/I7) |
| Display | LCD 14" 1366x768 high resolution / LED backlight / low temperature screen (optional touch screen) |
| RAM | DDR3 1366 4/8GB |
| HDD | 2*SATA3.0 |
| IO Interface | 1*LAN（1000/100Mbps), 1*HDA, 8*USB, 2/4*COM, 1*LPT, VGA+ HDMI + LVDS |
| Input device | Touchpad， 88 keyboard (silicone waterproof keyboard) |
| Expansion Slot | 1*Mini PCI-E (with SIM card holder, supporting 3G module, supporting m-sata) |
| Keyboard | Notebook waterproof keyboard, with touchpad mouse |
| Power Supply | DC12V 5A adapter |
| Cooling | Integrated heat dissipation |
| Working temperature | -15 ~ 70 ℃ |
| Impact | 30g peak, half-sine, 11ms pulse |
| Shock | 5 ~ 500Hz, 1.5grms; Non operating: 5-500 Hz, 3grms |
| Industry requirements | comply with GJB 151a national military standard CE, FCC, RoHS |
| Application | Intelligence, Communication, Electric Power, Outdoor Maintenance and Industrial Construction |
