组件名称规格尺寸(mm)358(L) x 256(W) x 140(H)材质采用全铝镁合金材料，可以非常方便搭建各种测试及监控系统，适用各种环境较恶劣场合CPUIntel E3 1230V3RAMDDR3 1600 8GB*2HDD位3*3.5" HDD+2*2.5"HDD/SSD(标配60G SSD)显示屏LCD 14" 1366x768高分辨率/LED背光/低温屏
Military industry, aviation, aerospace, aviation, power, communication, intelligent control.
| Components | Specification |
| Dimension | 58(L) x 256(W) x 140(H) |
| Material | Aluminum magnesium alloy, Build a variety of testing and monitoring systems, suitable for various harsh environments |
| CPU | Intel E3 1230V3 |
| Display | High brightness 14" LCD, 1366*768 resolution |
| RAM | DDR3 1600 8GB*2 |
| HDD | 3*3.5" HDD+2*2.5"HDD/SSD |
| IO Interface | 2*LAN(1000/100Mbps), 4*USB 3.0, 1*VGA, 1*E-sata |
| Input device | Touchpad, 88 keyboard (silicone waterproof keyboard) |
| Expansion Slot | Support one PCIEx16 expansion card |
| Keyboard | Notebook waterproof keyboard, with touchpad mouse |
| Power Supply | Flex 1U 300W |
| Cooling | 3*40mm fans |
| Working temperature | - 15 ~ 70 ℃ |
| Impact | 30g peak, half-sine, 11ms pulse |
| Shock | 5 ~ 500Hz, 1.5grms; Non operating: 5-500 Hz, 3grms |
| Industry requirements | comply with GJB 151a national military standard CE, FCC, RoHS |
| Application | Military industry, aviation, aerospace, airborne, power, communication, intelligent control, etc |
