Server storage, security monitoring, etc.
| Components | Specification |
| Dimensions(WxDxH) | 427mm x 650mm x 88.5mm, standard 19" rackmount chassis. |
| Materials | Quality fine 1.0mm SGCC steel, Aluminum profile al6063. |
| Color | Black. |
| Drivers bay | 9 x 3.5" HDD drive bays compatible 3 x 2.5" SSD drive bays. |
| Cooling Fan | 4 x 80mm fans. |
| PSU form factor | Standard 2U power supply or redundant power supply. |
| M/B form factor | Support MAX 12" x 13" motherboard. |
| Epansion space | 7 PCI/PCIE expansion slots. |
| Connector | Two front accessible USB2.0 ports. |
| System Control | POWER LED*1, HDD LED*1, RESET SW*1, POWER SW*1. |
| Applicarion | Server storage, security monitoring, etc. |
| Product Features: | |
1.Conformed with EMC design standard to prevent from electromagnetic interference. | |
| 2.Support motherboard size up to 12" x 13", and 9 x 3.5" HDD drive bays compatible 3 x 2.5" SSD drive bays, Standard 2U power supply or redundant power supply. | |
| 3.The chassis has good ventilation system 4 x 80mm fans to make sure the system work steadily. | |
