Product model:4U workstation

Indusrrial control, IOT, machine automation, communication, etc.

Components	Specification
Dimensions(WxDxH)	427mm x 450mm x 177mm.
Materials	Quality fine 1.2mm SGCC steel.
Display	Support 8.4" LCD display.
Color	Black.
Drivers bay	2 x 3.5" HDD drive bays, 1 x 5.25" CD-ROM bay.
Cooling Fan	2 x 90mm fans on front.
PSU form factor	Standard ATX power supply.
M/B form factor	Support MAX ATX 12" x 9.6" motherboard.
Epansion space	7 PCI expansion slots or 14 PCI expansion slots.
Input device	Slim notebook keyboard and touchable mouse pad.
Connector	One front accessible USB2.0 port.
System Control	Power switch, Reset switch, Power LED , HDD LED.
Applicarion	Indusrrial control, IOT, machine automation, communication, etc.

Product Features:
1.Conformed with EMC design standard to prevent from electromagnetic interference.
2.Support motherboard size up to ATX 12" x 9.6", and 2 x 3.5" HDD drive bays, 1 x 5.25" CD-ROM bay, Support 8.4" LCD display, Standard ATX power supply.
3.The chassis has good ventilation system 2 x 90mm fans on front to make sure the system work steadily.
