G-5835-P4 AI inference chassis supports up to five 3.5-wide gaming version GPU cards. It can optionally support two 2.5-inch SSDs. The chassis is equipped with three 12038 hot-swappable ball fans as standard, and the rear window is equipped with three A 12038 ball fan has good heat dissipation performance. The chassis is compatible with E-ATX/ATX motherboards of 12"*13" and below. It supports 5 standard CRPS power modules and 4+1 power supply mode, which is stable and reliable. The products are widely used in scenarios such as big data, AI, rendering, and deep learning. They perform well in aspects such as GPU computing performance, storage expansion capabilities, and system stability, and can best meet the needs of the development and application of emerging fields such as artificial intelligence.
| Component name | Detailed specifications and parameters |
| Dimensions(mm) | 830（L）*437.6（W）*220（H） |
| Main material | Magang (environmentally friendly, fingerprint resistant 1.2mm SGCC) |
| Surface treatment | The front panel assembly is sprayed with sand grain black, and the rest is natural color |
| GPU | Supports 5 3.5 wide GPU game cards (length 350MM) |
| Hard disk space | Optional front 2*2.5-inch SATA or NVME backplane |
Fan position | Standard configuration: 6 12038B fan positions |
| Motherboards | standard 12"*13" and below motherboards, the motherboard requires 5 PCIE4.0 X16 slots |
| I/O | 11 full-height PCI/PCIE expansion slots, vertical insertion |
| External interface | External interface 2 * USB 3.0 |
| System control | POWER LED*1，HDD LED*1，RESET SW*1，POWER SW*1，NIC LED*2 |
| Power supply | supports standard CRPS power module, 4+1 power supply mode |
| PCIE channel | 5*PCIE4.0 X16 |
| Front VGA | optional according to motherboard |
| Applicable fields | AI reasoning, rendering, HPC, deep learning and other fields |
