ComponentsSpecificationDimensions(mm)437.5mm x 650mm x 176.5mm, standard 19" rackmount chassis.Materials1.0mm SGCC Zinc-Coated Steel.Backplane6Gb/s MINI SAS backplane, with temperature control ch
Cloud storage, big data, private cloud, distributed storage, security monitoring
| Components | Specification |
| Dimensions(mm) | 437.5mm x 650mm x 176.5mm, standard 19" rackmount chassis. |
| Materials | 1.0mm SGCC Zinc-Coated Steel. |
| Backplane | 6Gb/s MINI SAS backplane, with temperature control chipset. / 12Gb/s MINI SAS backplane, with temperature control chipset. / 6Gb/s Expander backplane, with temperature control chipset. / 12Gb/s Expander backplane, with temperature control chipset. |
| Drivers bay | 12 x 3.5' hot-swappable SATA (II or III) / SAS (II or III) 6Gb/s drive bays. |
| Cooling Fan | Standard quotation with 3pcs 12038H ball bearing fans. |
| PSU form factor | Standard PS2 power supply or redundant power supply. |
| M/B form factor | Support MAX 12" x 13" motherboard. |
| Epansion space | 7 full-height PCI/PCIE expansion slots. |
| Connector | Two front accessible USB2.0 ports(Optional USB3.0). |
| System Control | Power LED*1，Reset*1，Power SW*1，HDD LED*1，NIC LED*2，UID LED*1，UID SW*1，OH/FAN Fail LED*1，Power Fail LED*1. |
| Applicarion | Cloud storage, cloud computing, big data, security monitoring, LOTetc. |
| Product Features: | |
1.Conformed with EMC design standard to prevent from electromagnetic interference. | |
| 2.Support motherboard size up to 12" x 13", and 12*3.5"HDD bays, Standard PS2 power supply or redundant power supply. | |
| 3.The chassis has good ventilation system 3pcs 12038H ball bearing fans to make sure the system work steadily. | |
