Committed to the research and development and production of industrial control chassis, server chassis, portable computers, reinforced notebooks, customized servers, distributed storage servers, GPU supercomputing servers, AI servers and various computer peripheral products
Components | Specification |
Dimensions(WxDxH) | 427mm x 480mm x 177mm, standard 19" rackmount chassis. |
Materials | Quality fine 1.2mm SGCC steel. |
Color | White. |
LCD screen | 8.4" LCD screen, optional resistive touch screen. |
Drivers bay | 2 x 3.5" HDD drive bays, 1 x 3.5" FDD bay, 3 x 5.25" CD-ROM bays. |
Cooling Fan | 1 x 120mm fan on front. |
PSU form factor | Standard PS2 power supply or redundant power supply. |
M/B form factor | Support MAX 12" x 9.6" motherboard. |
Epansion space | 7 PCI expansion slots or 14 PCI expansion slots. |
Connector | Two front accessible USB2.0 ports. |
System Control | POWER LED*1, HDD LED*1, KB-LK LED, RESET SW*1, POWER SW*1, KB-LK SW*1. |
Applicarion | Cloud storage, cloud computing, big data, security monitoring, etc. |
Product Features: | |
1.Conformed with EMC design standard to prevent from electromagnetic interference. | |
2.Support motherboard size up to 12" x 9.6", and 2 x 3.5" HDD drive bays, 1 x 3.5" FDD bay, 3 x 5.25" CD-ROM bays, Standard PS2 power supply or redundant power supply. | |
3.The chassis has good ventilation system 1 x 120mm fan to make sure the system work steadily. |
