Cloud storage, big data, private cloud, distributed storage, security monitoring
| Components | Specification |
| Dimensions(mm) | 438mm x 650mm x 88mm, standard 19" rackmount chassis. |
| Materials | 1.0mm SGCC Zinc-Coated Steel. |
| Backplane | 12Gb/s MiniSAS HD interface (12Gb Expander backplane), with temperature control, with SGPIO, with time-sharing startup, with hard disk short circuit protection, support cold storage |
| Drivers bay | Support 25x 2.5" HDD/SDD drive bays on the front,2*2.5''HDD/SDD drive bays on the back. |
| Cooling Fan | 3 x 8038mm fans |
| PSU form factor | Standard PS 2U or CRPS power supply |
| M/B form factor | Support MAX 12" x 13" motherboard. |
| Epansion space | 7 full-height PCI/PCIE expansion slots. |
| Connector | Two front accessible USB2.0 ports(Optional USB3.0), 1*VGA port. |
| System Control | Power LED*1，Reset*1，Power SW*1，HDD LED*1，NIC LED*2，UID SW*1,OH/FAN Fail LED*1，Power Fail LED*1 |
| Applicarion | Cloud storage, cloud computing, big data, security monitoring, LOTetc. |
| Product Features: | |
1.Conformed with EMC design standard to prevent from electromagnetic interference. | |
| 2.Support motherboard size up to 12" x 13", and 25x 2.5" HDD/SDD drive bays, Standard PS 2U or CRPS power supply. | |
| 3.The chassis has good ventilation system 3 x 8038mm fans to make sure the system work steadily. | |
