Support motherboard size up to ATX 12" x 9.6", and 2 x 3.5" HDD drive bays, 1 x 3.5" FDD bay, 1 x 5.25" CD-ROM bays, Standard PS2 power supply or redundant power supply.The chassis has good ventilation system 3 x 80mm fans to make sure the system work steadily.
Industrial control, intelligent transportation, Internet of things, mechanical automation, etc.
1.Conformed with EMC design standard to prevent from electromagnetic interference.
2.Support motherboard size up to ATX 12" x 9.6", and 2 x 3.5" HDD drive bays, 1 x 3.5" FDD bay, 1 x 5.25" CD-ROM bays, Standard PS2 power supply or redundant power supply.
3.The chassis has good ventilation system 3 x 80mm fans to make sure the system work steadily.
| Components | Specification |
| Dimensions(WxDxH) | 427mm x 450mm x 88mm, standard 19" rackmount chassis. |
| Materials | Quality fine 1.0/1.2mm SGCC steel. |
| Color | Silver and Blue. |
| Drivers bay | 2 x 3.5" HDD drive bays, 1 x 3.5" FDD bay, 1 x 5.25" CD-ROM bays. |
| Cooling Fan | 3 x 80mm fans on front. |
| PSU form factor | Standard 2U single power supply or redundant power supply. |
| M/B form factor | Support MAX ATX 12" x 9.6" motherboard. |
| Epansion space | 7 PCI expansion slots. |
| Connector | Two front accessible USB2.0 ports. |
| System Control | POWER LED*1, HDD LED*1, RESET SW*1, POWER SW*1. |
| Applicarion | Industrial control, intelligent transportation, Internet of things, mechanical automation, etc. |
