Industrial control, intelligent transportation, Internet of things, mechanical automation, etc.
| Components | Specification |
| Dimensions(WxDxH) | 427mm x 483mm x 88mm, standard 19" rackmount chassis. |
| Materials | Quality fine 1.0/1.2mm SGCC steel. |
| Color | Black. |
| Drivers bay | 2 x 3.5" HDD drive bays, 1 x 3.5" FDD bay, 1 x 5.25" CD-ROM bays. |
| Cooling Fan | 2 x 80mm fans on front. |
| PSU form factor | Standard 2U single power supply or redundant power supply. |
| M/B form factor | Support MAX ATX 12" x 9.6" motherboard. |
| Epansion space | 7 PCI expansion slots. |
| Connector | Two front accessible USB2.0 ports. |
| System Control | POWER LED*1, HDD LED*1, RESET SW*1, POWER SW*1. |
| Applicarion | Industrial control, intelligent transportation, Internet of things, mechanical automation, etc. |
| Product Features: | |
1.Conformed with EMC design standard to prevent from electromagnetic interference. | |
| 2.Support motherboard size up to ATX 12" x 9.6", and 2 x 3.5" HDD drive bays, 1 x 3.5" FDD bay, 1 x 5.25" CD-ROM bays, Standard PS2 power supply or redundant power supply. | |
| 3.The chassis has good ventilation system 2 x 80mm fans to make sure the system work steadily. | |
