Cloud storage, big data, private cloud, distributed storage, security monitoring
| Components | Specification |
| Dimensions(mm) | 437.5mm x 650mm x 44mm, standard 19" rackmount chassis. |
| Materials | 1.0mm SGCC Zinc-Coated Steel. |
| Backplane | 12Gb/s Mini-sas HD (SFF-8643 Interface) backplane, with temperature control chipset, SGPIO. |
| Drivers bay | 4 x 3.5" HDD(Compatible with 2.5" HDD/SSD). |
| CD-ROM bays | 1x slim CD-ROM bay(Compatible with 2.5" HDD/SSD). |
| Cooling Fan | 6pcs 40mm fans. |
| PSU form factor | Standard Supermicro 500W redundant power supply. |
| M/B form factor | Support MAX 12" x 13" motherboard. |
| Epansion space | 1 full-height PCI/PCIE expansion slots. |
| Connector | Two front accessible USB2.0 ports(Optional USB3.0). |
| System Control | Power LED*1, Reset*1, Power SW*1, HDD LED*1, NIC LED*2, UID LED*1, UID SW*1. |
| Applicarion | Srorage, security monitoring, cloud computing, LOT, etc. |
| Product Features: | |
1.Conformed with EMC design standard to prevent from electromagnetic interference. | |
| 2.Support motherboard size up to 12" x 13",and 4*3.5"HDD bays,1 slim CD-ROM ,Standard Supermicro 500W redundant power supply. | |
| 3.The chassis has good ventilation system 6pcs 40mm fans to make sure the system work steadily. | |
